Axes: 3-4
Payload: 3kg-8kg
Repeatability: ±0.1mm

SKU: h565-17201-45600 Category: Tag:

Key Industries and Applications:


Programmable through ACE software and eV+ language, or through the familiar IEC 61131-3 when using ePLC Connect

• The amplifier and controller built into the robot reduces the number of cables

• Tracks up to a conveyor speed of 1.4 m/s

• Designed with a high payload to support multi-hand (multi-picking)

• Supports fast Pick & Place on a fast conveyor

• Helps reduce mounting cost and robot vibration

• Maximum working diameter 1,130 mm

• Working height 425 mm

• Maximum payload 8 kg

• Weight 52 kg
