ATX – Mechatronic Solutions October 21st – 22nd, 2025
Use Promotional Code: INVITE914792
Mechatronic Solutions booth is 1803 at the ATX tradeshow on October 21st & 22nd at the downtown Minneapolis Convention Center.
View our Previous Recaps!
Represented Vendors
Click on The Icons Below To Learn More
Last Years Demos and Digital Booth
Check Back in September for Our Updated List!
Electronic Pin Assembly
In This Demo – Vision and Pick n’ Place
From Asyrils internal team: The developed demonstrator with the Asycube 80 flexible feeder and the Mecademic Scara MCS500 robot showcases an assembly application of compact electronic pins.
Key Components
Asyril Eye+
Asyril Asycube 80
MecaDemic MicroDash
Meca500 and Asycube240
In This Demo – Pin Pick and Place
The pins are randomly strewn about the Asycube 240.
From there, the Eye+ Snapshots the assortment and ideal pins for placement.
From there the Meca500 picks the pins identified by the Eye+ and places them sequentially in the pin tray.
Key Components
Mecademic Meca500
Asyril Asycube 240
Asyril Eye+
Schunk Gripper
ctrlX Core 3
TSLOTS Extrusion
ctrlX Automation Demo
See the entire lineup as it scales from a simple x3 core (for plc and edge device work) to the x7 (256 axes of motion, optional AI chip, and factory wide controller.) All with the same interface.
Key Components
ctrlX core 3
ctrlX core 7
ctrlX Drive
ctrlX Edge Device Demo
MQTT & Databasing via Node Red to Monitor the Omron LD Mobile Robot’s activity. Web based HMI and Grafana, to simplify control deployment.
Key Components
- ctrlX core x3
- Omron LD Mobile Robot
- Grafana Dashboard
ctrlX Motion Control & Databasing
Simple PLC and Motion Controller with local Databasing, Email Alerts, and a Web Based HMI.
Key Components
- ctrlX Core X3
- ctrlX Compact Drive
- Grafana Dashboard
Omron LD-90 and TMC130 Demo
In This Demo: AMR Material Handling
CtrlX Core using MQTT and Postgres Database via Node Red to monitor and control Omron LD90 mobile robot. Web-based HMI with imbedded Grafana Dashboard to view status of robot/jobs and send new commands. Mobile robots are used to autonomously pick up and deliver parts/carts around a facility
Key Components
• CtrlX Core X3 running Node Red, Grafana, & WebIQ
• Omron LD90 AMR with ROEQ Topper and Cart
• Weintek 15.6” Web panel
Yaskawa GP8
Yaskawa GP8 with Shunk dual EGK electric grippers. Showcasing the robots machine tending capabilities. Open cell design using Omron light curtains & area scanner to allow the robot to slow down and stop safety if an operator needs to interact with the cell. HTM bar lights are used to indicate the robot’s status.
Key Components
• Yaskawa GP8 6-Axis robot
• Omron OS32C area scanner & F3SG-SRA light curtains
• HTM IO-LINK light bars
Schunk Tool Changer with Yaskawa GP4
In This Demo – Agile Pick and Place
In this video, the Yaskawa Motoman GP4 will be performing a pick and place application.
The initial grab will be done with the Schunk 2-jaw gripper.
Part way through the sequence, the Schunk tool changer will dynamically switch out the 2-jaw for the 3-jaw gripper.
Key Components
Schunk 2-Jaw Gripper
Schunk 3-Jaw Gripper
Schunk Toolchanger
Yaskawa Motoman GP4
Omron OS32C Area Scanner
Festo VTUX Terminal
Machine Vision Table
In These Demos
Omron F430 – Barcode to OCR Comparisons.
Omron V440 – will be analyzing text on a polished metal surface.
Omron FHV7 – will be seeking small components on a Raspberry Pi Pico.
Pixelink Resolv4K – will be identifying airforce targets.
[FINAL DEMOS PENDING CHANGE]
Key Components
Omron F430
Omron V440 + CCS Flat Dome Light
Omron FHV7 + CCS Colored Ring Light
Pixelink Resolv4K
Omron i4H Scara Cell
In This Demo – Indexed Pallet Placement
Omron i4H SCARA sorting vials. Using ACE Sight to refine the part position and orientation. Omron V430 barcode reader is used to read the data matrix on each vile and sort into their appropriate pallets. Showcasing the robots speed, vision, & flexibility to work with external sensors.
Key Components
• Omron i4H 650 SCARA Robot
• Omron V430 Barcode Reader
• Schmalz Vacuum generator with air-saving functionality
Bell-Everman Robotic Transfer Unit
In This Demo
Bell-Everman has provided us with an excellent Robot Transfer Unit.
Mounted on this units is the Omron TM, which will be performing a machine tending demonstration across both sides of the assembly.
Key Components
Bell-Everman RTU
Omron TM
Bring Your Own Barcode
The Omron V460 is the best barcode scanner on the market and we want you to bring us your hardest barcodes so we can prove it!
The Eye+ Small Parts Test
Asyrils Eye+ Wizard is so intuitive and accurate, they want you to bring your small parts and show you how to train them on the Asyril Asycube Studio.
Represented Vendors
Click on The Icons Below To Learn More
ctrlX Giveaway!
For a Limited Time, have everything you need to get started with ctrlX.
We still have kits available, starting at $1,499.
Register to Win!
Afterparty at: The Local
Join us from 5:00 to 10:00 P.M. at the Local, just down the street from the convention center. There will be free food and drinks, plus ample opportunity to discuss any engineering challenges or impressive parts of the tradeshow!
