Mechatronic Solutions at ATX

Booth 1803  | October 10th – 11th 2023!

Mechatronic Solutions & Brits Pub Afterparty

October 10th, 5:00 P.M. – 9:00 P.M.

Mechatronic Solutions - ATX 2022

Watch the 2022 Recap Playlist!

ATX Vendor Presence

Over 20 Vendors Will Be Represented at Our Booth

Mechatronic Solutions Demos

10+ Demos Will Be Running Full Time

ATX – Mechatronic Solutions October 10th – 11th, 2023

Mechatronic Solutions booth is 1803 at the ATX tradeshow on October 10th & 11th at the downtown Minneapolis Convention Center

Additionally we will be having an afterparty across the street from the convention center at Brits Pub, October 10th at 5:00 P.M. to 9:00 P.M.

RSVP for Brits Pub Afterparty

This field is for validation purposes and should be left unchanged.

Represented Vendors

Click on The Icons Below To Learn More

Demo List and Digital Booth

Dorner ERT150 Demo

In This Demo

We showcase the Dorner ERT150 demo as it transports materials.

Once at two checkpoint, the Omron V430 and V330 will scan the vials as theypass.

From there, the NX102 processes that data and transmits it into a SQL server in real time.

Key Components

Dorner ERT150

Omron V330 Barcode Reader

Omron V430 Barcode Reader

Omron Nx102 PLC with SQL Databasing

Festo Pipetting Demo

In This Demo

A Gripper withdraws a tube from a rack while a machine vision camera verifies the barcode.

From there, the lid is withdrawn as a pipetting end effector distributes the liquid to a corresponding vial.

The lid is returned to the tube, reset in the rack and another tube is withdrawn to restart the process.

Key Components

Festo Distributors – VTOI-A-V8-30D3-U14-08-V-S015-1

Festo Pipetting Unit – DHOE-1-1-A-P-CS

Festo Valve Control Model – DHOE-1-1-A-P-CS

Festo Disposable Tip Ejector – DHAO-EJ-1-1-V1-CS

Asyril JennyScience Demo

In This Demo – Precise Pick and Place

The Asycube will vibrate the parts in the platform.

The Asyril Eye+ will locate the vertically oriented pins.

 The Jennyscience XYZ will then pick the confirmed vertically oriented pins and place them in a 4 slotted deposit within the retrieval disk.

Once filled, the retrieval disk rotates and vacuums the pins, returning them to the Asyril hopper.


Key Components

Asyril Asycube50

Asyril Eye+

JennyScience XYZ Pick and Place

Mecademic MCS500

In This Demo – Rapid Pick and Place

The MCS500 will be picking batteries from one plate and placing them on the other.

Powered by an Omron NX1P2 and an Omron HMI, live tracking and easy to use buttons allow the operator to work seamlessly.

Key Components

Mecademic MCS500

Omron NX1P2

Omron HMI

Machine Vision Table

In These Demos

Omron F430 – Barcode to OCR Comparisons.

Omron V440 – will be analyzing text on a polished metal surface.

Omron FHV7 – will be seeking small components on a Raspberry Pi Pico.

Pixelink Resolv4K – will be identifying airforce targets.

Key Components

Omron F430

Omron V440 + CCS Flat Dome Light

Omron FHV7 + CCS Colored Ring Light

Pixelink Resolv4K

Meca500 and Asycube240

In This Demo – Pin Pick and Place

The pins are randomly strewn about the Asycube 240.

From there, the Eye+ Snapshots the assortment and ideal pins for placement.

From there the Meca500 picks the pins identified by the Eye+ and places them sequentially in the pin tray.

Key Components

Mecademic Meca500

Asyril Asycube 240

Asyril Eye+

Schunk Gripper

Omron HMI

TSLOTS Extrusion

Yaskawa HC10 Collaborative Robot Demo

In This Demo

 The Yaskawa HC10 is performing a palletizing sequence.

Key Components

Yaskawa HC10 Collaborative Robot

Schmalz FQE Area Gripper

Yaskawa PalletSolver Software


Omron i4H Scara Cell

In This Demo – Indexed Pallet Placement

The i4H will place dice on a grid that sits on the Festo EGC-HD, gradually this grid will be indexing at stages from left to right.

Meanwhile the i4H will be stacking the dice sequentially as it is making this movement.

Once the grid is completely filled it will then rapidly go back and forth as the i4H unloads the grid back into the asycube.

ACE Sight captures information from the Asycube and the sequence repeats.

Key Components

Omron i4H SCARA

Omron NJ501-R

Asyril Asycube 240

Omron ACE Sight

Festo Linear Rail EGC-HD

Omron Door Locks

TSlots extrusion

Yaskawa GP8 Demo

In This Demo – 3D Bin Picking

The Photoneo will consistently track objects in a three-dimensional space.

The GP8 will then transport objects between two bins.

Meanwhile, Omron light curtains, area scanners, and TSlots hard-guarding keep this industrial presentation safe.

Key Components

Yaskawa GP8 Six-Axis Robot

Photoneo 3D Vision System

Omron Safety Light Curtains

Omron Area Scanner

TSlots Extrusion

Omron TM and LD Demo

In This Demo

The Omron TM is picking up a parts tray containing four different items.

The tray is then placed on the Dorner 2700 conveyor.

The NX1P2 PLC Handshakes the LD and TM

The TM Receives a signal to move the pallet

Then the LD receives a signal retrieve it from the conveyor.

Key Components

Omron TM Collaborative Robot

Omron LD Mobile Robot

Dorner 2700 MEdium Conveyor

Omron NX1P2

Omron Ethercat Coupler

More Demo Footage and Information to Come!
